HIKVISION HWD-5108H User Manual

Digital Video Recorder User Manual
61
Or press the PTZ button on the front panel or click the PTZ Control icon in the quick
setting bar, or select the PTZ option in the right-click menu to show the PTZ control panel.
Step 2 Click the General tab to show the general settings of the PTZ control.
Figure 4-8 PTZ Panel - General
Step 3 Select a patrol in the drop-down list and click the Call Patrol button to call it.
Step 4 You can click the Stop Patrol button to stop calling it.
4.2.5 Customizing Patterns
Purpose
Patterns can be set by recording the movement of the PTZ. You can call the pattern to make the PTZ
movement according to the predefined path.
Step 1 Go to Menu>Camera>PTZ.
Figure 4-9 PTZ Settings
Step 2 Choose pattern number in the drop-down list.
