Hirschmann OCTOPUS OS3 User Manual

16
Installation OCTOPUS OS3
Release 01 02/2019
1.6 Pin assignments
Figure 1: Pin assignments: Interfaces and ports
Pin
1 TX
2 RX
3 -
4 GND
Function
1
2
3
4
V24
1 Uin
2 -
3 D -
4 GND
5 D+
Pin Function
1
2
3
4
5
ACA
FunctionPin
1 P+
2
3 P -
4
5 PE
Do not use
Do not use
1
2
3
4
5
Power
1
2
3
4
5
Signal
FunctionPin
1 Bl_DB+
2 Bl_DB -
3 Bl_DA+
4 Bl_DA -
5 Bl_DC+
6 Bl_DC -
7 Bl_DD -
8 Bl_DD+
1
2
7
4
3
5
6
8
Port GE
FunctionPin
1 -
2
3
4 -
5
