Hisense AX3120G User Manual

21
13.
Model Name
AX3120G
Soundbar
Power Supply AC 100-240V~ 50/60Hz
Power Consumption
Standby Power
20 W
USB port for playback
USB Compatibility
5V
500mA
Hi-Speed USB (2.0) / FAT32 / FAT16
32G (max) , WAV/WMA/MP3/FLAC/ALAC
Dimension (WxHxD)
920 x 60 x 90 mm / 36.2" x 2.4" x 3.5"
Net weight 2.9 kg
Frequency Response 150Hz~20KHz
Operating Temperature 0°C - 45°C
Bluetooth frequency range
Bluetooth Max. transmitting power
(EIRP)
V5.3
2400 MHz ~ 2483.5 MHz
≤10 dBm
Modulation Type GFSK, π/4 DQPSK, 8DPSK
Subwoofer
Power Supply AC 100-240V~ 50/60Hz
Power Consumption 15 W
Standby Power < 0.50 W
Dimension (WxHxD)
214 x 294 x 304 mm / 8.4" x 11.6" x 12"
Net weight 5.27kg
Frequency Response 40Hz~180Hz
Total 360 W
Main Unit 240W
Subwoofer 120 W
Remote Control
Distance/Angle 19.7 feet (6m) / 30°
Battery type AAA (1.5V X 2)
Amplifier (Max Audio Power)
< 0.50 W

Hisense AX3120G Specifications

General

Audio decoders	DTS Virtual:X, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus
Equalizer modes	Bass, Movie, Music, TV
RMS rated power	360 W
Audio output channels	3.1.2 channels
Soundbar mode control	Yes
Rear speaker RMS power	0 W
Audio Return Channel (ARC)	No
Number of speakers	6
Soundbar speaker RMS power	240 W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	6.5 \
Product color	Black
Volume control	Buttons
Country of origin	China
Audio formats supported	MP3 VBR, MP4, WAV
Bluetooth version	5.3
Connectivity technology	Wired & Wireless
Export Control Classification Number (ECCN)	85182100
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Package depth	478 mm
Package height	1010 mm
Package weight	10300 g
Cables included	AC, HDMI, Optical

Weight and Dimensions

Depth	90 mm
Width	920 mm
Height	60 mm
Cord length	1.5 m
Soundbar weight	2900 g
Subwoofer depth	304 mm
Subwoofer width	214 mm
Subwoofer height	294 mm
Subwoofer weight	5200 g
