Hisense HS312 User Manual

7
3 4 5
1 2 3
13
6
OPT
1 2
7 8 9 10 11 12
Identifying the Parts
Main Unit
1 Remote Control Sensor
Receive signal from the remote control.
2 Display Window
Show the current status.
3
(ON/OFF) button
Switch the unit between ON and Standby
mode.
4
(SOURCE) button
Select the play function.
5 VOL+/VOL- buttons
Increase/decrease the volume level.
6 Screws
Remove the screws then install the wall
mounting screws into the back of the unit.
7 USB Socket
Insert the USB device to play music.
8 LINE IN Socket
Connect to an external audio device.
9 OPTICAL Socket
10 COAXIAL Socket
11 HDMI OUT (ARC) Socket
Connect to a TV via HDMI cable.
12 HDMI IN 1 / HDMI IN 2 Sockets
13 AC~ Socket
Connect to the power supply.
Wireless Subwoofer
1 AC~ Socket
Connect to power.
2 PAIR button
Press activate the pairing function between
the main unit and the subwoofer.
3 PAIR Indicator
Light stops blinking once the Subwoofer is
paired with the Soundbar.

Hisense HS312 Specifications

General

Audio decoders	Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
RMS rated power	300 W
Audio output channels	3.1 channels
Subwoofer type	Active subwoofer
Subwoofer included	Yes
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Subwoofer frequency range	40 - 120 Hz
Wi-Fi	No
HDMI in	2
HDMI ports quantity	3
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Product color	Black
Number of speakers	6
Soundbar speaker RMS power	180 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Soundbar power consumption	20 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	30 W
Cables included	AC, HDMI
Package depth	270 mm
Package width	1090 mm
Package height	365 mm
Package weight	10600 g

Weight and Dimensions

Depth	90 mm
Width	980 mm
Height	58 mm
Subwoofer depth	420 mm
Subwoofer width	240 mm
