- 13 -
2.2 MSD6308 includes product
Model Panel Mode LVDS(Main-Panel)
Main board Power board
LHD24N10NAM V236BJ1-LE2
1、HX2-2×20KLB400-BOE\ROH 2、
FFC-12-850\ROH
RSAG7.820.5650 RSAG7.820.5258
LHD32N10NAM HE315GH-E77
HX2-2×20KLB400-BOE\ROH RSAG7.820.5650 RSAG7.820.5268
LHD32K160NAMN
HE315GH-E77\ROH HX2-2X15KLB400P-CMO-3\ROH RSAG7.820.5645 RSAG7.820.5023
LTDN48K20DAM
HD480DF-B37
HX2-2x22KLB500P-HS-6\ROH
RSAG7.820.5645 RSAG7.820.5482
3. Factory/Service OSD Menu and Adjustment
3.1 How to enter the Factory OSD Menu
With user’s RC
Power on the TV.
1. Press “Menu” button and call up User OSD Menu.
2. Select “ Sound” -> “Balance” item.
3. Press number key 1->9->6 ->9 in sequence when “Balance” item is focused.
Note: If necessary, re-do number keys.
4. Factory OSD appears.
Note: Press “exit” key on the RC, which can exit factory OSD menu.
