16
22” TFT TV Service Manual
11.14. PI5V330
11.14.1. General description
Pericom Semiconductor’s PI5V series of mixed signal video circuits are produced in the Company’s
advanced CMOS low-power technology, achieving industry leading performance.
The PI5V330 is a true bidirectional Quad 2-channel multiplexer/demultiplexer that is recommended for both
RGB and composite video switching applications. The VideoSwitch™ can be driven from a current output
RAMDAC or voltage output composite video source.
Low ON-resistance and wide bandwidth make it ideal for video and other applications. Also this device has
exceptionally high current capability which is far greater than most
analog switches offered today. A single 5V supply is all that is required for operation.
The PI5V330 offers a high-performance, low-cost solution to switch between video sources. The
application section describes the PI5V330 replacing the HC4053 multiplier and buffer/amplifier.
11.14.2. Features
• High-performance, low-cost solution to switch between video sources
• Wide bandwidth: 200 MHz
• Low ON-resistance: 3W
• Low crosstalk at 10 MHz: –58 dB
• Ultra-low quiescent power (0.1 µA typical)
• Single supply operation: +5.0V
• Fast switching: 10 ns
• High-current output: 100 mA
• Packages available:
– 16-pin 300-mil wide plastic SOIC (S)
– 16-pin 150-mil wide plastic SOIC (W)
– 16-pin 150-mil wide plastic QSOP (Q)
11.14.3. Pin Descriptions
Pin Name Description
S1
A
, S2
A
S1
B
, S2
B
S1
C
, S2
C
S1
D
, S2
D
Analog Video I/O
IN Select Input
EN Enable
D
A
, D
B
,
D
C
, D
D
Analog Video I/O
GND Ground
V
CC
Power
