AV3000 AVC Unit Service Manual
7.2.2.
TC57587-01-401
8-way Digital Interface Cable Connector (P302P)
PIN
No:
AVC
(FC4)
PDP
1 TXD > TXD
2 RXD < RXD
3 PARITY > PARITY
4 REMO-PDP < REMO-PDP
5 AUDIO L > AUDIO L
6 AUDIO R > AUDIO R
7 PDDET < PDDET
8 AVDET2 > AVDET2
7.3.
FC4 Connectors
7.3.1. FPC Connector
FH12-50S-0.5SV 0.5mm pitch (PSF)
Pin
No.
AVC
PSF
Pin Name
FC4
P001
Pin Name
In/
Out
Function Notes
1 GND GND I/O I
2
C bus DATA
2 N.C. N.C. I/O I
2
C bus CLOCK
3 GND GND - GND
4 DATA DATA I/O 3-wire DATA 5V CMOS
5 CLK CLK I 3-wire CLOCK 5V CMOS
6 GND GND - GND
7 FC-ENA FC-ENA I FC micro enable 5V CMOS
8 MSC-ENA OSD-CS I MSC micro enable 5V CMOS
9 DATA OSD-DATA I 3-wire DATA 5V CMOS
10 CLK OSD-CLK I 3-wire CLOCK 5V CMOS
11 GND GND - GND
12 N.C. N.C.(2H) O 2H sync for OSD
13 N.C. K_DET I Enable for OSD generator
14 N.C. N.C.(2V) O 2V sync for OSD
15 N.C. KMASK I RESET for OSD generator
16 GND GND - GND
