AV3000 AVC Unit Service Manual
1. FEATURES
• 852x1024 resolution, created by 32" ALIS Plasma display panel
• 1024x1024 resolution, created by 37"/42" ALIS Plasma display panel
• Advanced progressive & 1024 interlace, generates detailed picture without flicker
• TruBass by SRS, gives real bass sound
• Thin (9cm) and light, by separating monitor from tuner box (AVC). It is possible to hang monitor
on the wall.
• Swivel stand attached monitor, possible to swivel 30deg left and right.
• 3 SCART connectors plus front AV input can be connected with DVD, Set Top Box, VCR and
camera at the same time.
• 1 Component input allows YP
b
P
r
and PC
b
C
r
to be received. Signal is automatically identified.
• PC input connection, supporting various PC display formats.
2. GENERAL SPECIFICATION
Model
32PD3000
(PDP; 32PD3000E + AVC; AV3000E)
42PD3000
(PDP; 42PD3000E + AVC; AV3000E)
PDP panel
32" (ALSI for mat) Plasma display panel (16:9),
resolution 852(H) x1024 (V)
42" (ALSI for mat) Plasma display panel (16:9),
resolution 1024(H) x1024 (V)
Display size 976 (W) x 258 (D) x 580 (H) mm 1233 (W) x 300 (D) x 713 (H) mm
Sound output
level
Max. 10W x2 (6W) Max. 12W x2 (6W)
Speaker 4x 16cm corn type x2 ???
Power supply AC 220~240V 50Hz AC 220~240V 50Hz
Power
consumption
PDP 260W (stand-by <2W) AVC 30W, (stand-by
<2W)
PDP 360W (stand-by <2W) AVC 30W, (stand-by
<2W)
Colour
system
PAL/SECAM/NTSC4.43/NTSC3.58/PAL60 PAL/SECAM/NTSC4.43/NTSC3.58/PAL60
Sound
system
I/B.G.H/LL' I/B.G.H/LL'
Tuning freq. 45~889MHz, VHF low/VHF high/Hyper/UHF 45~889MHz, VHF low/VHF high/Hyper/UHF
Position
selection
100 (0~99) positions. Plus channel direct (C--/S--)
and frequency direct (---.--MHz)
100 (0~99) positions. Plus channel direct (C--/S--)
and frequency direct (---.--MHz)
PC input
signal
Horizontal freq 24~109KHz / Vertical freq
50~85Hz.
Analogue RGB, input voltage 0.7/1.0 V
p-p
selectable.
H/V separate sync (TTL level) *** sound input;
common with AV3 or AV4
Horizontal freq 24~109KHz / Vertical freq
50~85Hz.
Analogue RGB, input voltage 0.7/1.0 V
p-p
selectable.
H/V separate sync (TTL level) *** sound input;
common with AV3 or AV4
AV input
SCART101 (CVBS/SVHS/LR sound) - AV1
SCART102 (CVBS/RGB/LR sound) - AV2
SCART100 (CVBS/RGB/LR sound) - AV3
COMPONENT (YPbPr/YCbCr/LR sound) - AV4
Front AV (CVBS/SVHS/LR sound) - FRONT
CENTRE AUDIO input
SCART101 (CVBS/SVHS/LR sound) - AV1
SCART102 (CVBS/RGB/LR sound) - AV2
SCART100 (CVBS/RGB/LR sound) - AV3
COMPONENT (YPbPr/YCbCr/LR sound) - AV4
Front AV (CVBS/SVHS/LR sound) - FRONT
CENTRE AUDIO input
Dimensions
PDP: 974 (W) x 256 (D) x 578 (H) mm including
monitor stand
AVC: 430 (W) x 293 (D) x 121 (H) mm
PDP: 1030 (W) x ?? (D) x 636 (H) mm including
monitor stand
AVC: 430 (W) x 293 (D) x 121 (H) mm
Weight
PDP: 28.7Kg (net)
AVC: 3.2Kg (net)
PDP: 40.2Kg (net)
AVC: 3.2Kg (net)
Remote 2x Hitachi R6P(G) * equivalent 'AA' 2x Hitachi R6P(G) * equivalent 'AA'
