43
ENGLISH
MENU
Audio
Timer
Function
Setup
Language
Select
OK Set
Contrast : + 31
Brightness : – 31
Colour : 0
Hue : + 31
Picture Enhancement : Off
Colour Temperature : Normal
Colour Temp.Adjust
Reset Reset
Select Set Return
OK
Contrast + 31
Next / Prev Adjust Return
Contrast : + 31
Brightness : – 31
Colour : 0
Hue : + 31
Picture Enhancement : Off
Colour Temperature : Normal
Colour Temp.Adjust
Reset Reset
Select Set Return
OK
Colour Temperature Normal
Next/Prev Select Return
Contrast : + 31
Brightness : – 31
Colour : 0
Hue : + 31
Picture Enhancement : Off
Colour Temperature : Normal
Colour Temp.Adjust
Reset Reset
Select Set Return
OK
Colour Temp. Adjust On
Amplitude
Red – 63
Green 0
Blue – 31
Cut Off
Red + 31
Green 0
Blue + 31
Reset Reset
Select On/Off Return
Selected characters
Contrast
Narrows the gap between
brightness and darkness.
Broadens the gap between
brightness and darkness.
Setup hint
Adjust for maximum visibility to suit the ambient brightness.
This can adjust further till [+40] by pressing and holding cursor
button at [+31]. The color for [+32] to [+40] numbers will change from
white to magenta. This special mode is better for dark scenes.
For brighter scene some parts of the picture might not be clear. We
recommend to set at [+31].
"Panel Life" in the Function Menu should be set to Normal when
Contrast setting is adjusted.
Off Low Middle High
Cool Normal Warm Black / White
Off On
Brightness
Black is subdued for
increased overall darkness.
Black is set off for increased
overall brightness.
Adjust to taste.
Picture Enhancement
Sets the clarity of small details to the desired level.
Colour Temperature
Normally set to Normal.
Colour Temp. Adjustment
Amplitude
Cut Off
Reset
Turn On when you wish to change colour temperature is required to
adjust depending on the user’s preference.
The original factory settings for the items of this Menu page can be
restored by pressing the OK button.
Colour
Darkens colours. Lightens colours. Adjust to taste.
Hue
Enhances red and weakens
green.
Enhances green and weak-
ens red.
This is not available to adjust when receiving PAL/SECAM signal.
In this case the character will be grayed out.
Adjust for most realistic skin colour.
Brighter scene is decreased
in reddish colour.
Brighter scene is increased
in reddish colour.
Brighter scene is decreased
in greenish colour.
Brighter scene is increased
in greenish colour.
Brighter scene is decreased
in bluish colour.
Brighter scene is increased
in bluish colour.
Dark scene is decreased in
reddish colour.
Dark scene is increased in
reddish colour.
Dark scene is decreased in
greenish colour.
Dark scene is increased in
greenish colour.
Dark scene is decreased in
bluish colour.
(off the function)
Dark scene is increased in
bluish colour.
(waiting to reset)
Red
Green
Blue
Red
Green
Blue
Adjust colour temperature depending on the user’s preference. These
settings are independently stored in each of the 4 Colour Temperature
modes.
OPERATING INSTRUCTIONS (continued)
PICTURE MENU (RBG mode)
