54
Pin
4
3
2
1
Frame
4
3
2
1
Pin
RGB terminal (D-sub 15-pin connector)
• When different kinds of input signals are simultaneously input to
the monitor via a graphics board or the like, the monitor will
automatically select the signals in the following priority order:
* Even in the case of the recommended signals shown on the
following page, there may be instances when correct display is not
possible. In this case, use H/V separate sync, H/V composite sync.
S-input connector pin specifications
Photo-input connector pin specifications
HDMI connector pin specifications
Pin Input signal
1R (P
R
/C
R
)
2 G or sync on green (Y)
3B (P
B
/C
B
)
4 No connection
5 No connection
6 R.GND (P
R
/C
R
, GND)
7 G.GND (Y, GND)
8 B.GND (P
B
/C
B
, GND)
9 No connection
10 GND
11 No connection
12 [SDA]
13 H. sync or H/V composite sync
14 V.sync. [V.CLK]
15 [SCL]
( ) : With component input
Input signal
Y
Y-GND
C
C-GND
GND
Input signal
5V
DM
DP
GND
Pin
Input signal Pin
Input signal
1
2
3
4
5
6
7
8
9
10
TMDS Data2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data 1+
TMDS Data1 Shield
TMDS Data1-
TMDS Data0+
TMDS Data0 Shield
TMDS Data0-
TMDS Clock+
11
12
13
14
15
16
17
18
19
TMDS Clock Shield
TMDS Clock-
CEC
Reserved(N.C. on device)
SCL
SDA
DDC/CED Ground
+5V Power
Hot Plug Detect
Sync signal type
H/V separate sync.
sync.on Green *
H/V composite sync.
Priority
1
2
3
PRODUCT SPECIFICATIONS (continued)
Signal Input
