English
10
2. Battery Charger (UC18YRSL)
Fig. 2
SPECIFICATIONS
1. Cordless jig saw
Model CJ14DSL CJ18DSL
Motor DC motor
No-Load Speed 0-2,400/min
Capacity Wood 5-5/16" (135mm)
Mind steel 3/8" (10mm)
Stroke 1" (26mm)
Min. cutting radius 1" (25mm)
Model BSL1430 BSL1830
Type Lithium – ion battery
Battery
Voltage DC 14.4V DC 18V
Capacity 3.0 Ah
Weight 5.1 lbs (2.3 kg) 5.3 lbs (2.4 kg)
Pilot lamp
Cord
Nameplate
Guide rail
2. Battery Charger (UC18YRSL)
NOTE: The charging time may vary according to ambient temperature and power source voltage.
Input power source Single phase: AC 120 V 60 Hz
Charging time Approx. 45 min.
Charger
Charging voltage DC 14.4 V 18 V
Charging current DC 3.5 A
Weight 1.3 lbs. (0.6 kg)
01Eng_CJ14DSL_US 08/11/7, 09:3210
