11
English
Do not connect
air hose
(2) Adjust the air pressure to 64 psi (4.4 bars
4.5 kgf/cm
2
).
Connect the air hose.
Do not load any nails in the Nailer.
□ The Nailer must not leak air.
Hold the Nailer downward, without touching
the lock lever and pull the trigger.
□ The Nailer must not operate.
(3) If no abnormal operation is observed, you
may load nails in the Nailer.
Drive nails into the workpiece that is
the same type to be used in the actual
application.
□ The Nailer must operate properly.
ADJUSTING AIR PRESSURE
WARNING
Do not exceed 100 psi (6.9 bars 7 ●
kgf/cm
2
).
Adjust the air pressure at recommended
operating pressure 64 – 100 psi (4.4 – 6.9 bar
4.5 – 7 kgf/cm
2
) according to the length of nails
and the hardness of workpiece.
The correct air pressure is the lowest pressure
which will do the job. Using the Nailer at a
h ig he r t ha n r eq ui re d a i r pressure unnecessarily
over stresses the Nailer.
LOADING NAILS
WARNING
When loading nails into Nailer, ●
1) disconnect air hose
2) do not pull trigger and lock lever;
and
3) keep Nailer pointed downward.
NOTE
Use 5 or more connected nails.
(1) 1 Disconnect air hose from Nailer.
2 Lightly depress the stop lever.
3 Pull out the magazine cover slowly.
Magazine
cover
Stop lever
1
2
3
Disconnect
air hose
000BookNP35AUS.indb11000BookNP35AUS.indb11 2009/08/1015:44:442009/08/1015:44:44
