Hitachi S1 Series User Manual

S1 series standard inverter
-13-
3.6 Rated value
3.6.1 AC 1PH 220V(-15%)-240V(+10%)
Inverter model
Power class
(kW)
Input current (A)
Output current (A)
ND rating
LD rating
ND rating
LD rating
S1-00032SFE
0.4/0.75
6.5
7
2.5
3.2
S1-00055SFE
0.75/1.1
9.3
12
4.2
5.5
S1-00100SFE
1.5/2.2
15.7
24
7.5
10
S1-00130SFE
2.2/3
24
30
10
13
3.6.2 AC 3PH 380V(-15%)–440V(+10%)
Inverter model
Power class
(kW)
Input current (A)
Output current (A)
ND rating
LD rating
ND rating
LD rating
S1-00032HFE
0.75/1.1
3.4
4.7
2.5
3.2
S1-00055HFE
1.5/2.2
5.0
5.8
4.2
5.5
S1-00073HFE
2.2/3
5.8
10
5.5
7.3
S1-00125HFEF
4/5.5
13.5
19.5
9.5
12.5
S1-00170HFEF
5.5/7.5
19.5
23
14
17
S1-00230HFEF
7.5/11
25
30
18.5
23
S1-00320HFEF
11/15
32
40
25
32
S1-00380HFEF
15/18.5
40
47
32
38
S1-00450HFEF
18.5/22
47
51
38
45
S1-00600HFEF
22/30
51
70
45
60
S1-00750HFEF
30/37
70
80
60
75
S1-00920HFEF
37/45
80
98
75
92
S1-01150HFEF
45/55
98
128
92
115
S1-01500HFEF
55/75
128
139
115
150
S1-01700HFEF
75/90
139
168
150
170
S1-02150HFEF
90/110
168
201
180
215
S1-02600HFEF
110/132
201
265
215
260
S1-03050HFEF
132/160
265
310
260
305
S1-03400HFEF
160/185
310
345
305
340
S1-03800HFEF
185/200
345
385
340
380
S1-04250HFEF
200/220
385
430
380
425
S1-04800HFEF
220/250
430
460
425
480
S1-05300HFEF
250/280
460
500
480
530
S1-06000HFEF
280/315
500
580
530
600
S1-06500HFEF
315/355
580
625
600
650
S1-07200HFEF
355/400
625
715
650
720
S1-08600HFEF
400/500
715
890
720
860
