SJ200 Inverter
Configuring
Drive Parameters
3–39
“B” Function
Run
Mode
Edit
Defaults
Func.
Code
Name /
SRW Display
Description
–FEF
(EU)
–FU
(USA)
Units
B088 Restart mode after FRS Selects how the inverter
resumes operation when the
free-run stop (FRS) is
cancelled, two options:
00...Restart from 0Hz
01...Restart from frequency
detected from real speed of
motor (frequency matching)
✘ 00 00 —
RUN FRS ZST
B090 Dynamic braking usage
ratio
Selects the rate of use (in %) of
the regenerative braking
resistor per 100 sec. intervals,
range is 0.0 to 100.0%
0% .Dynamic braking disabled
>0% Enabled, per value
✘ 0.0 0.0 %
BRD %ED 0000.0%
B091 Stop mode selection Selects how the inverter stops
the motor, two option codes:
00...DEC (decelerate and stop)
01...FRS (free run to stop)
✘ 00 00 —
STP Slct DEC
B092 Cooling fan control Selects when the fan is ON per
inverter operation, two options:
00...Fan is always ON
01...Fan is ON during run,
OFF during stop (5 min.
delay from ON to OFF)
02...Fan is temperature-
controlled
✘ 00 00 —
FAN-CTRL OFF
B095 Dynamic braking
control
Three option codes:
00...Disable
01...Enable during RUN only
02...Enable always
✘ 00 00 —
BRD Slct OFF
B096 Dynamic braking
activation level
Range is:
330 to 380V (200V class),
660 to 760V (400V class)
✘ 360/
720
360/
720
—
BRD LVL 00360V
B130 Over-voltage
LADSTOP enable
Pauses deceleration ramp when
DC bus voltage rises above
threshold level, in order to
avoid over-voltage trip.
Two option codes:
00...Disable
01...Enable
✘ 00 00 —
OVLADSTOP OFF
B140 Over-current trip
suppression
Two option codes:
00...Disable
01...Enable
✘ 00 00 —
I-SUP Mode OFF
