SJ200 Inverter
Getting Started
1–7
SJ200 Inverter Specifications, continued...
Item 200V Class Specifications, continued
SJ200 inverters,
200V models
EU version 015NFEF 022NFEF — — —
USA version 015NFU 022NFU 037LFU 055LFU 075LFU
Applicable motor size *2 kW 1.5 2.2 3.7 5.5 7.5
HP 2 3 5 7.5 10
Rated capacity
(kVA)
230V 3.1 4.3 6.9 9.5 12.7
240V 3.3 4.5 7.2 9.9 13.3
Rated input voltage 1-phase: 200 to 240V ±10%, 50/60 Hz ±5%,
3-phase: 200 to 240V ±10%, 50/60 Hz ±5%,
(037LFU, 055LFU, 075LFU 3-phase only)
Integrated EMC
filter
EU version Single phase filter,
Category C3 *5
—
USA version —
Rated input
current (A)
1-phase 17.5 24.0 — — —
3-phase 10.0 14.0 22.0 30.0 40.0
Rated output voltage *3 3-phase: 200 to 240V (proportional to input voltage)
Rated output current (A) 8.0 11.0 17.5 24 32
Starting torque *7 200% or more 180% or more
Dynamic braking
approx. %
torque, short
time stop *8
without resistor,
from 50 / 60 Hz
70%: ≤ 50Hz
50%: ≤ 60Hz
20%: ≤ 50Hz
20%: ≤ 60Hz
with resistor 150% 100% 80%
DC braking Variable operating frequency, time, and braking force
Weight
EU version
(-NFEF
kg 1.9 1.9 — — —
lb 4.2 4.2 — — —
US version
(-NFU)
kg 1.8 1.8 1.9 5.5 5.7
lb 3.97 3.97 4.2 12.13 12.57
