MAINTENANCE
7-57
1
Check Coolant Level --- daily
CAUTION: Do not loosen radiator filler cap (1) unless
the system is cool. Loosen cap (1) slowly to the stop.
Release all pressure before removing cap (1).
With the engine cold, the coolant level must be between
the FULL and LOW marks on coolant reservoir (2), located
behind the radiator access door. If the coolant level is below
the low mark, add coolant to coolant reservoir (2).
If coolant reservoir (2) is empty, add coolant to the radiator
and then to coolant reservoir (2).
M1U1-07-024
1
M1U1-07-022
FULL
LOW
2
M1U1-07-081
1
M1U1-07-082
FULL
LOW
M1U1-07-106
M1U1-07-107
ZX200-3, 270-3 , 330-3 Class
ZX180-3 Class
ZX120-3 Class
ZX180-3 Class
ZX200-3, 270-3 , 330-3 Class
ZX120-3 Class
1
2
FULL
LOW
2
To Next Page
