Hitachi ZAXIS 200-3 class User Manual

OPTIONAL ATTACHMENTS AND DEVICES
13-39
SHOE TYPES AND APPLICATIONS
ZX250LC-3 2-piece Boom
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
900 mm (35”)
Triangular Shoe
Application
For Ordinary
Ground
(Standard)
For Weak
Footing
(Option)
For Weak
Footing
(Option)
For Paved Road
(Option)
For Weak
Footing
(Option)
Operating Weight kg
(lb)
25600
(56400)
25900
(57100)
26200
(57800)
26300
(58000)
27700
(61100)
Base Machine Weight kg
(lb)
19600
(43200)
19900
(43900)
20200
(44500)
20300
(44800)
21700
(47800)
Cab Height mm
(ft•in)
3010
(9’11”)
3010
(9’11”)
3010
(9’11”)
3020
(9’11”)
3060
(10’1”)
Minimum Ground mm
Clearance (ft•in)
✹
460
(18”)
✹
460
(18”)
✹
460
(18”)
500
(20”)
✹
460
(18”)
Undercarriage mm
Length (ft•in)
4640
(15’3”)
4640
(15’3”)
4640
(15’3”)
4660
(15’4”)
4750
(15’7”)
Undercarriage Width mm
(ft•in)
3190
(10’6”)
3290
(10’10”)
3390
(11’1”)
3190
(10’6”)
3490
(11’5”)
Ground Pressure
51 kPa
(0.52 kgf/cm
2
,
7.4 psi)
44 kPa
(0.45 kgf/cm
2
,
6.4 psi)
39 kPa
(0.40 kgf/cm
2
,
5.7 psi)
52 kPa
(0.53 kgf/cm
2
,
7.5 psi)
36 kPa
(0.37 kgf/cm
2
,
5.3 psi)
ZX250LCN-3 2-piece Boom
Shoe Width
600 mm (24”)
Grouser Shoe
700 mm (28”)
Grouser Shoe
800 mm (31”)
Grouser Shoe
600 mm (24”)
Flat Shoe
900 mm (35”)
Triangular Shoe
Application
For Ordinary
Ground
(Standard)
For Weak
Footing
(Option)
For Weak
Footing
(Option)
For Paved Road
(Option)
For Weak
Footing
(Option)
Operating Weight kg
(lb)
25500
(56200)
25800
(56900)
26100
(57500)
26300
(58000)
27600
(60800)
Base Machine Weight kg
(lb)
19500
(43000)
19800
(43700)
20100
(44300)
20200
(44500)
21600
(47600)
Cab Height mm
(ft•in)
3010
(9’11”)
3010
(9’11”)
3010
(9’11”)
3020
(9’11”)
3060
(10’1”)
Minimum Ground mm
Clearance (ft•in)
✹
460
(18”)
✹
460
(18”)
✹
460
(18”)
500
(20”)
✹
460
(18”)
Undercarriage mm
Length (ft•in)
4640
(15’3”)
4640
(15’3”)
4640
(15’3”)
4660
(15’4”)
4750
(15’7”)
Undercarriage Width mm
(ft•in)
2990
(9’10”)
3090
(10’2”)
3190
(10’6”)
2990
(9’10”)
3290
(10’10”)
Ground Pressure
51 kPa
(0.52 kgf/cm
2
,
7.4 psi)
44 kPa
(0.45 kgf/cm
2
,
6.4 psi)
39 kPa
(0.40 kgf/cm
2
,
5.7 psi)
52 kPa
(0.53 kgf/cm
2
,
7.5 psi)
36 kPa
(0.37 kgf/cm
2
,
5.3 psi)
NOTE: • The specifications for the front-end attachment is for 2.19 m (7 ft 2 in) arm with PCSA 1.0 m
3
(1.3 yd
3
) bucket.
• 700, 800 mm (28, 31 in) grouser shoe, 600 mm (24 in) flat shoe and 900 mm (35 in) triangular shoe should not be
used on gravel or rocky ground.
•
✹
The dimensions do not include the height of the shoe lug.
