Hitachi ZAXIS 200-3 class User Manual

SPECIFICATIONS
12-37
SPECIFICATIONS
ZX350LC-3, 350LCN-3
Model ZX350LC-3 ZX350LCN-3
Type of Front-End Attachment 3.20 m (10 ft 6 in) Arm
Bucket Capacity (Heaped) PCSA 1.4 m
3
(1.83 yd
3
), CECE 1.2 m
3
(1.57 yd
3
)
Operating Weight 33300 kg (73400 lb) 33200 kg (73200 lb)
Base Machine Weight 25500 kg (56200 lb) 25400 kg (56000 lb)
Engine Isuzu AH-6HK1XYSA-01 202 kW/1900 min
–1
(275 PS/1900 rpm)
A: Overall Width
(Excluding back mirrors)
3190 mm (10 ft 6 in) 3000 mm (9 ft 10 in)
B: Cab Height
3140 mm (10 ft 4 in)
C: Rear End Swing Radius
3390 mm (11 ft 2 in)
D: Minimum Ground Clearance
* 500 mm (20 in)
E: Counterweight Clearance
* 1160 mm (3 ft 10 in)
F: Engine Cover Height
* 2590 mm (8 ft 6 in)
G: Overall Width of Upperstructure
2990 mm (9 ft 10 in)
H: Undercarriage Length
4940 mm (16 ft 3 in)
I: Undercarriage Width
3190 mm (10 ft 6 in) 3000 mm (9 ft 10 in)
J: Sprocket Center to Idler Center
4050 mm (13 ft 3 in)
K: Track Shoe Width
600 mm (24 in) (Grouser shoe)
Ground Pressure 63 kPa (0.64 kgf/cm
2
, 9.1 psi) 62 kPa (0.63 kgf/cm
2
, 9.0 psi)
Swing Speed 10.7 min
–1
(rpm)
Travel Speed (fast/slow) 5.0/3.2 km/h (3.1/2.0 mph)
Gradeability 35° (tanθ = 0.70)
NOTE: * The dimensions do not include the height of the shoe lug.
M1V1-12-003
A
G
B
D
K
I
C
F
E
J
H
