5-2
• When lift arm control lever (1) is pushed further from
the LOWER position (B) to the FLOAT position (C), the
lift arm is stopped in that position soon after the lift
arm reaches the position set by the lift arm auto-lev-
eler system. Then, the lever is automatically returned
to the HOLD position (N). (Only machines equipped
with the lift arm auto-leveler system)
NOTE: When operating the machine with the lift arm held in
the FLOAT position (C), first stop the lift arm in the float
position. Then, again move the lift arm control lever to
the FLOAT position (C) to allow the lift arm to come in
contact with the ground.
M4GB-01-043
M4GB-01-072
To Next Page
