HiWeigh X722 User Manual

3
1. Technical Specifications
Model#
X722#|#X722s#
Enclosure#Type#
ABS#|#Stainless#Steel#
Product#Dimension#
240x180x105mm#(X722)#
250x205x68mm#(X722s)#
Accuracy#
Class#III#
Display#Resolution#
1/3,000#–#1/60,000#
Internal#Resolution#
300,000#–#600,000#
Sampling#Rate#
20times/s#
Display#
6#digits#LCD#(40mm)#with#backlit#
Power#
100-240V-12V1Ah#AC/DC#Adapter#
Power#Consumption:#
About#12mA#
-with&backlight&
About&36mA&
-with&backlight&and&RS232&
About&48mA&
Rechargeable#Battery#
6V4Ah#(around#320 hrs #with ou t#ba ck light) #
Load#cell#Sensitivity#
0.6#–#3.0mV/V#
Sensitivity#
0.12uV/d#minimum#
Load#Cell#Quantity#
1-8#*#350OΩ#or#1-16*750Ω
Excitation#voltage#
5#VDC#
Units#
Kg#|#lb,#g#|#oz,#etc.#
Non-linearity#
≤ 0.01%F.S.
Operating#Temperature#
-10~45#
Storage#Temperature#
-25~55#
Relative#humidity#
85%Rh#non-condensing#
Communication#
Optional#isolated#RS232,#Bluetooth,#WiFi,#Relay,#etc.#
Shipping#Weight#
2.3-3.2kg#
2. Model Identification
#
Model:## # ##X722######S##-####UK#####0######0###
Corresponding:# ######A########B#########C######D######E#
#
A#=#Main#model#name#
B#=#Enclosure:## # -A#(or#none):# ABS#
# # # # -S:## # Stainless#Steel#
#
C#=#Plug#type,#examples:#
#
#
#
#
#
#
#
AU#=#Australia#Type#
CN#=#China#Type#
EU#=#EU#Type#
US#=#USA#Type#
SA#=#South#Africa#Type#
UK#=#UK#Type#
