Electrical Installations
06-1
Main elements of the electric system
• "PC-100HB and PC-100HB T" CONTROL PANEL -
controls the electric power consumers,
• 12V DISTRIBUTON MODULE "DS-300HB" -
main relay, battery parallel relay (12V - 70A), refrigerator
relay, pump relay, charging facility B1, safety fuses.
• BATTERY LOADING DEVICE -
loads the battery in buffer operation.
• PROBE WITH ROD -
measures contents of fresh water tank, 4-state visualisation
• PROBE WITH SCREWS "SSP" -
LED display shows when sewage tank is full
• CONSUMER BATTERY "B2" -
supplies all consumers
• VEHICLE BATTERY "B1"
• GENERATOR -
loads both the vehicle and consumer batteries at the same
time
• 230V MAIN SWITCH -
supplies and protects the 230V consumers
• 50A FUSES VEHICLE/ and CONSUMER BATTERIES
Chapter 6: Electrical Installations
6.1 Safety instructions
The following must be observed:
• Do not remove the signs on electrical components giving
safety instructions or danger warnings.
• Do not use the installation compartments for the caravan
battery, on-board control panel, battery charger and 230 V
connector box as additional storage room.
• Smoking and open re are forbidden when checking elec-
trical equipment.
• Only authorised and experienced workshops may carry out
electrical repairs.
• Inexpert handling of the vehicle‘s electrical system may
endanger your own life as well as that of others.
• Use only weatherproof, 3-wired extension cable and shock-
proof plug or CEE plug and coupler when hooking up to an
external 230 V network.
6.2 HOBBY on-board control panel
The electric power supply is provided via the HOBBY on-board
control panel in connection with an automatic battery charger.
