Electrical Installations
06-4
8) Signals that generator is charging vehicle and consumer
batteries.
9) LED signals test of vehicle battery; blinking signals empty
battery.
10) LED signals test of consumer battery; blinking signals
empty battery.
11) LED signals that 230V mains is connected.
12) LED voltmeter for monitoring voltage of vehicle and con-
sumer batteries.
13) Control switch for sewage tank resistance; dependent on
main switch and functions when motor is switched on or
230V mains is connected.
14) Switch for water pump that operates pump relay; depen-
dent on main switch.
15) Main switch for consumers; blinking LED signals that
consumer battery is almost empty and protection against
total discharge will soon be activated.
Functions
Protection against total discharge
An electronic installation turns off all 12V consumers when the
consumer battery reaches a minimum voltage of 10V. The con-
sumers can be switched on again for approx. one minute by
switching the main switch on again.
The refrigerator, electric entrance step and those consumers
directly supplied by B2 are not affected by this installation.
