Electrical Installations
06-12
The following applies if one of the devices breaks down:
•
Check the fuse on the corresponding electric cir
cuit.
•
Press the operating button.
•
If
the fuse
goes off
again, please
speak to
your
authorised
Hobby dealer
.
Char
ger with fuse box
•
The
charger
with
separate
fuse
box
is
located
under
the
passenger seat.
