(1)
RIGHT HANDLEBAR
(2)
OFF
RUN
(1) start button
(2) engine stop switch
29
Start Button Engine Stop Switch
Controls & Features
Instruments & Controls
Starting Procedure,
The start button ( ) is used for starting the
engine. Pushing the button in starts the
engine. See page .
The electric starter will only work when
the rear brake lever is pulled in and the
side stand is up.
The engine will not operate if the engine
stop switch is in the OFF position when
the start button is pushed.
The engine stop switch ( ) is used to stop
the engine in an emergency. To operate,
push the switch to the OFF position. The
switch must be in the RUN position to
start the engine, and it should normally
remain in the RUN position even when the
engine is OFF.
When the start button is pushed, the starter
motor will crank the engine; the headlight
will automatically go out, but the position
light, taillight and license light will stay on.
1
56
2
08/07/14 17:20:54 31MGF600 0038 
