22 lbs (10 kg).
(4)
(5)
(2)
(3)
(1)
(4) hooks
(5) seat catch
(1) center compartment
(2) ignition key
(3) seat lock
47
Center Compartment
Cargo Compartments
Before Riding
However, regardless of compartment
capacity, be sure you do not exceed the
maximum load and cargo weight limits.
The center compartment ( ) is designed to
carry up to
To Open the Center Compartment
Insert the ignition key (2) into the seat
lock (3) and turn it clockwise.
To Close the Center Compartment
Lower and push down on the opposite
side of the hooks (4) until it locks.
Remove the ignition key from the seat
lock.
1.
2.
1
