157
SPECIFICATIONS
MODEL BF80A
Description
code
BBLJ
Type LHT LRT XRT
Overall length 904 mm
(35.6 in)
746 mm
(29.4 in)
Overall width 646 mm
(25.4 in)
449 mm
(17.7 in)
Overall height 1,566 mm
(61.7 in)
1,693 mm
(66.7 in)
Transom height
(when Transom
angle is 12°)
537 mm
(21.1 in)
664 mm
(26.1 in)
Dry mass
(weight)*
171 kg
(377 lbs)
165 kg
(364 lbs)
171 kg
(377 lbs)
Rated power 58.8 kW (80 PS)
Full throttle
range
5,000 – 6,000 min
-1
(rpm)
Engine type 4 stroke OHC in-line 4-cylinder
Displacement
1,496 cm
3
(91.3 cu-in)
Spark plug gap 0.8– 0.9 mm (0.031 – 0.035 in)
Remote
control
steering
system
—
Motor-mounted,
remote control
Starter system Electric starter
Ignition system Full transistor battery
Lubrication
system
Trochoid pump pressure lubrication
Specified oil Engine: API standard (SG, SH, SJ) SAE 10W-30
Gear case: API standard (GL-4) SAE 90 Hypoid
gear oil
Engine oil
capacity
Engine: Without oil filter replacement:
4.2 L (4.4 US qt, 3.7 Imp qt)
With oil filter replacement:
4.4 L (4.6 US qt, 3.9 Imp qt)
Gear case: 0.95 L (1.00 US qt, 0.84 Imp qt)
D.C. output 12 V – 35 A
Cooling system Water cooling with thermostat
Exhaust system Water exhaust
Spark plug ZFR6K-9E (NGK)
Fuel pump Low pressure side:
High pressure side:
mechanical type
electrical type
Fuel Automotive unleaded gasoline
(91 research octane, 86 pump octane, or higher)
Gear shift Dog type: Forward – Neutral – Reverse
Steering angle 30° right and left
Trim angle – 4° to 16° (when Transom angle is 12°)
Tilt up angle 68° (when Transom angle is 12°)
Transom angle 8°, 12°, 16°, 20°, 24°
* Without battery cable, with propeller
Honda outboards are power rated in accordance with ISO8665 (propeller shaft output).
