Left Side Cover
#
Removal
1.
Remove the bolt.
2.
Remove the prong from the grommet.
3.
Remove the left side cover.
#
Installation
Install the parts in the reverse order of
removal.
20161122161659_32KZZE200_eng_BOOK Page 57 Tuesday, November 22 2016 16:19:28 JST
Removing & Installing Body Components u Left Side Cover
Maintenance
54
Bolt
Left side cover
Grommet
Prong

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda CRF250L 2019 and is the answer not in the manual?

Honda CRF250L 2019 Specifications

General IconGeneral
Displacement249.6cc
Bore x Stroke76.0mm x 55.0mm
Compression Ratio10.7:1
Transmission6-speed
Final DriveChain
Front Suspension43mm inverted fork
Rear SuspensionPro-Link single shock
Front BrakeSingle 256mm disc
Rear BrakeSingle 220mm disc
Front Tire3.00-21
Rear Tire120/80-18
Wheelbase56.9 inches
Fuel Capacity2.1 gallons
StarterElectric
Fuel SystemPGM-FI
Trail113mm
Engine TypeLiquid-cooled, single-cylinder, four-stroke
