Honda CRF250X User Manual

100 Servicing Your Honda
Battery Charging
Be sure to read the information that came with
your battery charger and follow the instructions
on the battery. Improper charging may damage
the battery.
We recommended using a “trickle” charger (1)
for home charging. These units can be left
connected for long periods without risking
damage to the battery. However, do not
intentionally leave the charge connected longer
than the time period recommended in the
charger’s instructions.
Avoid using an automotive-type battery charger.
An automotive charger can overheat a
motorcycle battery and cause permanent damage.
(1) “trickle” charger
(1)
Battery
The battery is located under the seat.
Removal
1. Remove the seat (page 35).
2. Remove the battery band (1).
3. Remove the positive terminal cover (2).
4. Disconnect the negative (–) terminal (3) first,
then the positive (+) terminal (4) and remove
the battery (5).
(1) battery band (4) positive (+) terminal
(2) positive terminal cover (5) battery
(3) negative (–) terminal
5. Unless you have been riding regulary, charge
the battery (see page 100).
6. Store your battery in an easy-to-reach location
off the floor, in an area protected from
freezing temperatures and direct sunlight.
7. Clean the battery box after removing the
battery for storage. Dry the battery box.
8. Slow charge the battery (see page 100) once
every 30 days.
(3)
(4)
(5)
(2)
(1)
Installation
1. Reinstall in the reverse order of removal. Be
sure to connect the positive (+) terminal first,
then the negative (–) terminal.
2. Check all bolts and other fasteners are secure.
250X_084-103.qxd 08.7.3 11:13 ページ100

Honda CRF250X Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore and Stroke	78.0mm x 52.2mm
Compression Ratio	12.9:1
Induction	Keihin 37mm flat-slide carburetor
Ignition	CDI
Transmission	Wide-ratio five-speed
Front Suspension	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4 inches travel
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/100-18
Trail	113mm (4.4 inches)
Wheelbase	58.3 inches
Seat Height	37.7 inches
Fuel Capacity	1.9 gallons
Final Drive	520 chain; 13T/51T
Rake	27.5 degrees
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and 13-position compression damping adjustability; 12.4 inches travel
Curb Weight	254 lbs (Includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
