Honda CRF250X User Manual

60 Servicing Your Honda
Refer to Safety Precautions on page 25.
Hot Start Lever Freeplay
(1) hot start lever
(2) freeplay
Inspection
Check freeplay:
2.0 – 3.0 mm (0.08 – 0.12 in)
If necessary, adjust to the specified range.
Adjustment
Adjustments can be made with the cable end
adjuster.
Loosen the lock nut (3) and turn the adjuster (4).
Turning the adjuster in direction (+) will increase
freeplay and turning it in direction (–) will
decrease freeplay. After adjustment, tighten the
lock nut.
(3) lock nut (+) increase
(4) adjuster (–) decrease
Hot Start Lever
(1)
(2)
(4)
(3)
250X_030-059.qxd 08.7.3 10:10 ページ60

Honda CRF250X Specifications

General

Engine Type	249cc liquid-cooled single-cylinder four-stroke
Bore and Stroke	78.0mm x 52.2mm
Compression Ratio	12.9:1
Induction	Keihin 37mm flat-slide carburetor
Ignition	CDI
Transmission	Wide-ratio five-speed
Front Suspension	47mm inverted Showa cartridge fork with 16-position rebound and 16-position compression damping adjustability; 12.4 inches travel
Front Brake	Single 240mm disc with twin-piston caliper
Rear Brake	Single 240mm disc
Front Tire	80/100-21
Rear Tire	100/100-18
Trail	113mm (4.4 inches)
Wheelbase	58.3 inches
Seat Height	37.7 inches
Fuel Capacity	1.9 gallons
Final Drive	520 chain; 13T/51T
Rake	27.5 degrees
Rear Suspension	Pro-Link Showa single shock with spring preload, 17-position rebound damping adjustability, and 13-position compression damping adjustability; 12.4 inches travel
Curb Weight	254 lbs (Includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
