Engine Mode & Launch Control System Indicator & Torque Control Indicator
10 Instruments & Controls
Engine Mode & Launch Control System Indicator & Torque Control Indicator
The engine mode indicator (blue) (1) is located
under the engine mode select button (2). The
engine mode indicator indicates the currently
selected mode by blinking the mode number once
when the engine is started.
The engine mode indicator indicates a selected
mode when you operate the engine mode select
button (page 140).
If the engine mode indicator stays on or does not
come on when it should, have your dealer check it
for problems.
The launch control system indicator (purple) (1) is
located under the engine mode select button (2).
The launch control system indicator indicates the
currently selected level by blinking the level
number while launch control system goes into
standby.
The launch control system indicator (purple)
comes on while the system is operating.
If the launch control system indicator does not
come on when it should, have your dealer check it
for problems.
The Torque Control indicator (green) (1) is
located to the right side of the Torque Control
button (2) on the left side of the handlebar.
Torque Control indicator (green) indicates the
currently selected mode by blinking the mode
number thrice when the engine is started.
The Torque Control indicator (green) comes on
while the system is operating.
The Torque Control indicator indicates a selected
mode when you operate the Torque Control button
(page 141).
If the Torque Control indicator does not come on
when it should, have your dealer check it for
problems.
Engine Mode Indicator
(1) engine mode indicator (blue)
(2) engine mode select button
(2)
(1)
Launch Control System Indicator
(1) launch control system indicator (purple)
(2) engine mode select button
(2)
(1)
Torque Control Indicator
(1) Torque Control indicator (green)
(2) Torque Control button
(2)
(1)
