Honda EG5000X User Manual

15
GENERATOR USE
CONNECTIONS TO A BUILDING ELECTRICAL SYSTEM
Improper connections to a building electrical system can allow
electrical current from the generator to backfeed into the utility lines.
Such backfeed may electrocute utility company workers or others
who contact the lines during a power outage, and the generator may
explode, burn, or cause fires when utility power is restored. Consult
the utility company or a qualified electrician.
GROUND SYSTEM
SPECIAL REQUIREMENTS
There may be Federal or State Occupational Safety and Health
Administration (OSHA) regulations, local codes, or ordinances that
apply to the intended use of the generator. Please consult a qualified
electrician, electrical inspector, or the local agency having jurisdiction.
Honda portable generators have a system ground that connects
generator frame components to the ground terminals in the AC output
receptacles. The system ground is not connected to the AC neutral
wire. If the generator is tested by a receptacle tester, it will not show
the same ground circuit condition as for a home receptacle.
If the generator is used at a construction site, there may be
additional regulations that must be observed.
In some areas, generators are required to be registered with local
utility companies.
Connections for standby power to a building electrical system must be
made by a qualified electrician. The connection must isolate the
generator power from utility power, and must comply with all
applicable laws and electrical codes. A transfer switch, which isolates
generator power from utility power, is available through authorized
Honda generator dealers (see page ).47
09/03/03 15:46:21 31ZC2770_016

Honda EG5000X Specifications

General

Type	Portable Generator
Power Output	5000 Watts
Engine Type	4-Stroke, OHV
Displacement	389 cc
Fuel Type	Gasoline
Starting System	Recoil Start
AC Output	120/240V
Receptacles	1x 120V 20A, 1x 120/240V 30A
DC Output	12V, 8A
Noise Level	68 dB

Summary

Understanding Generator Safety Principles

Generator Maintenance Essentials

Generator Safety Guidelines

Critical Safety Information for Generator Users

Generator Controls and Operation

Oil Alert System Functionality

Voltage Selector Switch Operation

Generator Use and Electrical Connections

Connecting to a Building Electrical System

Details requirements for connecting the generator to a building's electrical system via a qualified electrician.

Appliance Compatibility and AC Applications

AC Operation Procedures

AC Receptacle Selection Guide

Voltage Selector Switch Power Output

Details the power available at each receptacle based on the voltage selector switch position.

Pre-Operation Checks

Engine Oil Level Check

Guides on checking the engine oil level, the type of oil to use, and the procedure for checking.

Starting the Generator Engine

Maintenance Safety Precautions

Generator Maintenance Schedule

Engine Oil Change Procedure

Air Cleaner Service and Cleaning

Spark Plug Service and Replacement

Generator Storage Procedures

Storage Procedures by Duration

Provides recommended service procedures for preventing hard starting based on storage duration (less than 1 month to over 1 year).

Draining Carburetor and Fuel Tank for Storage

Details procedures for draining the carburetor float bowl and the fuel tank for proper storage preparation.

Cylinder Corrosion Protection During Storage

General Storage Precautions

Generator Troubleshooting Guide

Troubleshooting Engine Start Issues

Guides users through checks for fuel, oil, and spark plug condition when the engine fails to start.

Troubleshooting No AC Receptacle Power

Provides troubleshooting steps for when the generator produces no electricity at the AC receptacles, checking the circuit breaker and appliances.
