31
FUEL SEDIMENT CUP CLEANING
SEDIMENT CUP
O-RING
SEDIMENT CUP
FUEL FILTER
O-RING
FUEL VALVE
LEVER
The sediment cup prevents dirt or water that may be in the fuel tank
from entering the carburetor. If the engine has not been run for a long
time, the sediment cup should be cleaned.
Clean the sediment cup, O-ring, and filter in non-flammable or high
flash point solvent.
Turn the fuel valve lever to the OFF position. Remove the sediment
cup, O-ring, and filter.
Reinstall the filter, O-ring, and sediment cup.
Turn the fuel valve lever ON and check for leaks.
1.
2.
3.
4.
09/03/03 15:48:24 31ZC2770_032
