Honda EG6500CXS User Manual

9-1
9
9. STARTING SYSTEM
STARTING SYSTEM DIAGRAM
(CXS TYPE ONLY) ········································9-2
STARTING SYSTEM TROUBLESHOOTING
(CXS TYPE ONLY) ········································9-3
RECOIL STARTER REMOVAL/
INSTALLATION·············································9-4
RECOIL STARTER DISASSEMBLY·············9-5
RECOIL STARTER ASSEMBLY···················9-6
RECOIL STARTER INSPECTION ················ 9-8
STARTER MOTOR REMOVAL/
INSTALLATION (CXS TYPE ONLY) ············ 9-9
STARTER MOTOR DISASSEMBLY/
ASSEMBLY (CXS TYPE ONLY)················· 9-10
STARTER MOTOR INSPECTION
(CXS TYPE ONLY)······································ 9-11
82Z30000.book 1 ページ ２０１０年６月２５日 金曜日 午後５時５０分

Honda EG6500CXS Specifications

General

AC Output	120/240V
Displacement	389 cc
Engine	Honda GX390
Rated Power	5.5 kVA
Maximum Power	6.5 kVA
DC Output	12V
Starting System	Electric
