1.3 US gal (5 )
0.21 US gal (0.8
)
(1)
(2)
(1) fuel gauge
(2) red band
17
Fuel Gauge
Gauges & Indicators
Instruments & Controls
The fuel gauge ( ) shows the approximate
fuel supply available. At F (Full), the fuel
tank capacity including reserve is:
When the gauge needle enters the red band
( ), fuel will be low and you should refill
the tank as soon as possible.
The amount of fuel left in the tank when
the needle enters the red band is
approximately:
1
2
05/06/03 13:27:44 31GV4770_026
