Honda EU20I User Manual

−
16
PRE-OPERATION CHECK
4.
Be sure to check the generator on a level surface with the engine
stopped.
Using non detergent oil or 2-stroke engine oil could shorten the
engine’s service life.
Recommended oil
AMBIENT TEMPERATURE
Check the engine oil level.
Use 4-stroke motor oil that meets or exceeds the requirements for API
service category SE or later (or equivalent). Always check the API
service label on the oil container to be sure it includes the letters SE or
later (or equivalent).
SAE 10W 30 is recommended for general use. Other viscosities
shown in the chart may be used when the average temperature in
your area iswithin the recommended range.
1.

Honda EU20I Specifications

General

Model	EU20i
Type	Inverter
Engine	Honda GX100
Starting System	Recoil
Noise Level at 1/4 Load	53 dB(A)
Weight	21 kg
Inverter	Yes
Maximum AC Output	2000 VA
Rated AC Output	1600W
Displacement	98.5 cm³
AC Output	230V
DC Output	12V, 8A
