Honda EU20I User Manual

28
ACCircuitProtector(B,F,G,GP3,GWandWtypes)
AC RECEPTACLE No. 1 AC RECEPTACLE No. 2
CIRCUIT PROTECTOR
(For receptacle No. 1)
CIRCUIT PROTECTOR
(For receptacle No. 2)
ON
OFF
The AC circuit protectors will automatically switch OFF (push button
comes out) if there is a short circuitorasignificant overload of the
generator at receptacle.
If an AC circuit protector switches OFF automatically, check that the
appliance isworking properly and does not exceed the rated load
capacity of the circuit before resetting the AC circuit protector ON
(pushing the push button in).

Honda EU20I Specifications

General

Model	EU20i
Type	Inverter
Engine	Honda GX100
Starting System	Recoil
Noise Level at 1/4 Load	53 dB(A)
Weight	21 kg
Inverter	Yes
Maximum AC Output	2000 VA
Rated AC Output	1600W
Displacement	98.5 cm³
AC Output	230V
DC Output	12V, 8A
