Honda EU20I User Manual

41
AIR CLEANER SERVICE
Do not use gasoline or low flash point solvents for cleaning. They are
flammable and explosive under certain conditions.
Never run the generator without the air cleaner. Rapid engine wear
may result.
2.
MAINTENANCE COVER
MAIN AIR CLEANER ELEMENT
MAINTENANCE
COVER SCREW
OUTER AIR CLEANER
ELEMENT
AIR CLEANER ELEMENT
AIR CLEANER COVER
Adirty air cleaner will restrict air flow to the carburetor. To prevent
carburetor malfunction, service the air cleaner regularly. Service more
frequently when operating the generator in extremely dusty areas.
Loosen the maintenance cover screw and remove the maintenance
cover.
Reinstall the maintenance cover and tighten the cover screw
securely.
Reinstall the main and outer air cleaner elements and the air cleaner
cover. Tighten the cover screw securely.
Soak the elements incleanengine oil and squeeze out the excess oil.
Wash the main and outer air cleaner elements in a non-flammable
or high flash point solvent and dry them thoroughly.
Loosen the air cleaner cover screw, and remove the air cleaner cover.
3.
1.
2.
4.
5.
6
.

Honda EU20I Specifications

General

Model	EU20i
Type	Inverter
Engine	Honda GX100
Starting System	Recoil
Noise Level at 1/4 Load	53 dB(A)
Weight	21 kg
Inverter	Yes
Maximum AC Output	2000 VA
Rated AC Output	1600W
Displacement	98.5 cm³
AC Output	230V
DC Output	12V, 8A
