36
HONDA EX4D/5D (E) 36ZC8625 -36-
10. REMOTE CONTROL KIT
Remote Control Kit
(Installation)
• Remove the cap from the 7-pin connector on the generator maintenance
cover, and connect the 7-pin connector of the remote control switch box
cable there.
CAUTION: Be sure to install the cap on the connector when the remote
control kit is not used.
CAUTION:
• Do not pull on the remote control cable with excessive force when
disconnecting it from the connector.
• Do not leave tools, parts or other objects on the remote control
cable or move things over it.
• Do not direct jet water to the remote control box.
7 PIN CONNECTOR
REMOTE CONTROL CABLE
EX4D_5D_EN.book Page 36 Wednesday, April 8, 2009 3:31 PM
