40
HONDA EX4D/5D (E) 36ZC8625 -40-
11. SPECIFICATIONS
Dimensions
Engine
Generator
Model EX4D, EX5D
Description code EZCE
Length x Width x Height 1040 x 590 x 705 mm
(40.9 x 23.2 x 27.8 in)
Dry weight 200 kg (441 Ib)
Model GD411
Engine type 4-stroke, overhead valve, single cylinder diesel
Displacement 411 cm
3
(25.1 cu in)
Bore x Stroke 82 x 78 mm (3.2 x 3.1 in)
Max. output
6.7 kW (9.0 HP)/3,600 min
-1
(rpm)
Max. torque 20.6 N·m (2.1 kgf·m, 15.2 lbf·ft)/2,500 min
-1
(rpm)
Cooling system Forced air
Fuel Diesel fuel
Fuel tank capacity 26 lit. (27.5 US qt, 22.9 Imp qt)
Oil capacity 1.25 lit. (1.32 US qt, 1.10 Imp qt)
Model EX4D EX5D
Ty p e B F, G V L C
AC
output
Rated voltage (V) 115/230 230 120/240 120/240
Rated frequency (Hz) 50 50 60 60
Rated current (A) 32.2/16.1 16.1 37.5/18.8 37.5/18.8
Rated output (kVA) 3.7 3.7 4.5 4.5
Maximum output (kVA) 4.1 4.1 — —
EX4D_5D_EN.book Page 40 Wednesday, April 8, 2009 3:31 PM
