Honda GX240U1 User Manual

29
SERVICING YOUR ENGINE
TRANSMISSION OIL LEVEL CHECK
2 : 1 Reduction Transmission With Centrifugal Clutch
(applicable engine types)
UPPER LIMIT
LOWER LIMIT
FILLER CAP/DIPSTICK
Check the transmission oil level with the engine stopped and in a level
position.
Remove the filler cap/dipstick and wipe it clean.
Insert and remove the dipstick without screwing it into the filler hole.
Check the oil level shown on the dipstick.
If the oil level is low, add oil to reach the upper limit mark on the
dipstick. Use the same oil that is recommended for the engine (see
page 28).
Screw in the filler cap/dipstick securely.
1.
2.
3.
4.
03/08/21 20:10:44 31ZH9613_030

Honda GX240U1 Specifications

General

Compression Ratio	8.5:1
Starting System	Recoil start
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Engine Type	4-stroke, single cylinder
Net/Max Power Output	7.5 HP (5.5 kW) @ 3600 RPM
Weight	25 kg (55 lbs)
Displacement	242 cm3 (14.8 cu in)
