Honda GX240U1 User Manual

48
TECHNICAL & CONSUMER INFORMATION
TECHNICAL INFORMATION
Serial Number Location
SERIAL NUMBER
& ENGINE TYPE
ELECTRIC
STARTER
(applicable
types only)
Engine serial number:
Record the engine serial number in the space below. You will need this
serial number when ordering parts, and when making technical or
warranty inquires (see page ).60
03/08/21 20:13:47 31ZH9613_049

Honda GX240U1 Specifications

General

Compression Ratio	8.5:1
Starting System	Recoil start
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Engine Type	4-stroke, single cylinder
Net/Max Power Output	7.5 HP (5.5 kW) @ 3600 RPM
Weight	25 kg (55 lbs)
Displacement	242 cm3 (14.8 cu in)
