110
Specifications
Specifications
■ Main Components
*1
Including rider, passenger, all luggage, and accessories
*2
Includes the weight of the luggage and added accessories.
Overall length
III CA 1,847 mm (72.7 in)
IV CA, V CA 1,856 mm (73.1 in)
Overall width
686 mm (27.0 in)
Overall height
III CA 1,062 mm (41.8 in)
IV CA, V CA 1,059 mm (41.7 in)
Wheelbase
III CA 1,257 mm (49.5 in)
IV CA, V CA 1,256 mm (49.4 in)
Minimum ground
clearance
III CA 143 mm (5.6 in)
IV CA, V CA 141 mm (5.6 in)
Caster angle 26º 30´
Trail
III CA 85 mm (3.3 in)
IV CA, V CA 84 mm (3.3 in)
Curb weight
III CA 98 kg (216 lb)
IV CA, V CA 96 kg (212 lb)
Maximum weight
capacity*
1
117 kg (258 lb)
Maximum luggage
weight*
2
Centre compartment 5 kg (11 lb)
Inner racks and hook 1.5 kg (3.3 lb)
Passenger capacity Rider and 1 passenger
Minimum turning
radius
1.80 m (5.91 ft)
Displacement 108.20 cm
3
(6.600 cu-in)
Bore × stroke 50.000 × 55.106 mm (1.9685 × 2.1695 in)
Compression ratio 9.5:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuel containing alcohol ETHANOL up to 10% by volume
Tank capacity 4.0 litres (1.06 US gal, 0.88 lmp gal)
Battery
FTZ6V or YTZ6V
12 V-5 Ah (10 HR)
Primary reduction V-Matic (2.52:1 to 0.82:1)
Final reduction 10.625
20 ACF110BT CBT (CA)-32K93D10.book Page 110 Tuesday, February 18, 2020 4:43 PM
