18
COOLING FINS
Inspection
1. Loosen the socket bolt, then remove the top cover.
2. Inspect the engine cooling fins, and clean out debris if necessary.
3. Install the top cover, and tighten the socket bolt securely.
FUEL FILTER AND FUEL TANK
Fuel filter inspection and Fuel tank cleaning
1. Check that the engine oil filler cap is tightened securely.
2. Remove the fuel tank cap, and drain the fuel into an approved
gasoline container by tipping the powerhead toward the fuel filler
neck.
Gasoline is highly flammable and explosive.
You can be burned or seriously injured when handling fuel.
• Stop the engine and let it cool before handling fuel.
• Keep heat, sparks, and flame away.
• Handle fuel only outdoors.
• Keep away from your vehicle.
• Wipe up spills immediately.
COOLING FINS
(Inside the top cover)
3. Pull out the fuel filter with the mechanic’s wire from the fuel filler
neck gently.
4. Inspect the fuel filter. If the fuel filter is dirty, wash it gently with non-
flammable or high flash point solvent. If the fuel filter is excessively
dirty, replace it.
5. Remove water and dirt from the fuel tank by rinsing the inside of the
fuel tank with non-flammable or high flash point solvent.
6. Insert the fuel filter into the fuel tank and tighten the fuel tank cap
securely.
FUEL TUBE
Inspection
Check fuel tubes for cracks and any other deterioration and confirm that
there is no leakage of fuel on the fuel tubes. If you notice any abnormal
symptoms on the fuel tubes, contact your servicing dealer.
ENGINE OIL FILLER CAP
FUEL FILLER NECK
FUEL TANK CAP
31VP86080.fm 18 ページ ２０２３年１０月５日 木曜日 午後２時２２分
