r::iJ\
HONDA
NU50·
NU50M
BRAKE
SHOE
INSPECTION
Replace tne brake shoes if
the
arrow
on
the
brake
arm
aligns
with
Ihe reference
mark
"."
on
full
application
of
the
frollt
or
rear
brake
(Page
11
- 13,
12
-4).
FRONT
ARROW
MARK
REAR
MAINTENANCE
MARK
I
ARROW
SUSPENSION
FRONT
Check the
action
of
thc
front
forks
by
compressing
them
several times.
Check the
entire
lork
assembly
for
sig05
of
damagiL
Replace any components
which
CilnnOl
be repaired.
Tighten all
nuls
ilnd bolts
10
the
specified
torque
values (Page 1- 41.
REAR
Place
the
motorcycle
on
the
center
stand.
Hold
the
leaf
carrier
by
one
hand
and
move
the
hd!
crankcase
sideways
with
force
to
see
if
the
5wingarm
bushings ilfe
worn.
Replace If excessively
worn.
Check the entire suspension
aSlOcmbly.
Be
sure
it
is
securely
mounted
ilnd
not
damilged.
Tighten
all
nuts
and
bolu
to
the specified
torque
values {Page 1- 4}.
BUSHINGS
Dale
of Issue: Nov., 1981
©
HONDA
MOTOR CO., LTD.
31
