Specifications
Specifications
■ Main Components
*1 Including rider, passenger, all luggage, and accessories
*2 Includes the weight of the luggage and added accessories.
Type JC51
Overall length 1,873 mm (73.7 in)
Overall width 709 mm (27.9 in)
Overall height 1,080 mm (42.5 in)
Wheelbase 1,227 mm (48.3 in)
Minimum ground
clearance
135 mm (5.3 in)
Caster angle 26º 30´
Trail 68 mm (2.7 in)
Curb weight 99 kg (218 lb)
Maximum weight
capacity
*1
170 kg (375 lb)
Maximum luggage
weight
*2
9 kg (20 lb)
Passenger capacity Rider and 1 passenger
Minimum turning radius 1.90 m (6.27 ft)
Displacement 109.1 cm
3
(6.66 cu-in)
Bore × stroke 50.0 × 55.6 mm (1.97 × 2.19 in)
Compression ratio 9.0:1
Fuel
Unleaded petrol
Recommended: 90 RON or higher
Tank capacity 3.7 litres (0.98 US gal, 0.81 Imp gal)
Battery YTX4L-BS 12V-3Ah (10HR) / 3.2Ah (20HR)
Gear ratios
1st 2.615
2nd 1.555
3rd 1.136
4th 0.916
Reduction ratios
(primary / final)
4.059 / 2.642
12 AFS110-32KWWH00.book 103 ページ ２０１１年１０月２６日 水曜日 午後５時２２分
