■ Service Data
Tyre size
Front 70/90-17M/C 38P
Rear 80/90-17M/C 50P
Tyre type Bias-ply, tube
Recommended
Tyres
Front CHENG SHIN C-6016
Rear CHENG SHIN C-6016R
Tyre air
pressure
Front
[Rider only]
200 kPa (2.00 kgf/cm
2
, 29 psi)
[Rider and 1 passenger]
200 kPa (2.00 kgf/cm
2
, 29 psi)
Rear
[Rider only]
225 kPa (2.25 kgf/cm
2
, 33 psi)
[Rider and 1 passenger]
280 kPa (2.80 kgf/cm
2
, 41 psi)
Spark plugs (standard) CPR6EA-9S
Spark plug gap 0.80 to 0.90 mm (0.031 to 0.035 in)
Idle speed 1,400 ± 100 rpm
Recommended
engine oil
Honda 4-stroke motorcycle oil
API Service Classification SG or higher,
excluding oils marked as “Energy Conserving,”
SAE 10W-30, JASO T 903 standard MA
Engine oil
capacity
After draining
0.8 litres (0.8 US qt,
0.7 Imp qt)
After disassembly
1.0 litres (1.1 US qt,
0.9 Imp qt)
Recommended
brake fluid
Honda DOT 3 or DOT 4 Brake Fluid
12 AFS110-32KWWH00.book 104 ページ ２０１１年１０月２６日 水曜日 午後５時２２分
