Specifications
■ Main Components
Overall length 1,935 mm (76.2 in)
Overall width 740 mm (29.1 in)
Overall height 1,105 mm (43.5 in)
Wheelbase 1,315 mm (51.8 in)
Minimum ground
clearance
135 mm (5.3 in)
Caster angle 26º 30’
Trail
ED type 79 mm (3.1 in)
KO type 80 mm (3.1 in)
Curb weight 130 kg (287 lb)
Maximum weight
capacity
*1
ED type 180 kg (397 lb)
KO type 160 kg (353 lb)
Maximum luggage
weight
*2
13 kg (29 lb)
Centre compartment 10 kg (22 lb)
Front box 1.0 kg (2.2 lb)
Rear carrier 5 kg (11 lb)
Passenger capacity Rider and 1 passenger
Minimum turning radius 1.90 m (6.2 ft)
*1 : Including rider, passenger, all luggage, and accessories.
*2 : Includes the weight of the luggage and added accessories.
Displacement 125 cm
3
(7.6 cu-in)
Bore x stroke 53.5 x 55.5 mm (2.11 x 2.19 in)
Compression ratio 11.5:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuel containing alcohol ETHANOL up to 10 % by volume
Tank capacity 8.1 L (2.14 US gal, 1.78 Imp gal)
Battery
ED type
YTZ8V
12 V-7.0 Ah (10 HR) / 7.4 Ah (20 HR)
KO type
GTZ8V
12 V-7.0 Ah (10 HR)
Primary reduction V-Matic (2.65:1-0.81:1)
Final reduction 10.352
Specifications
162
