Fire Panels Specification for the Repeat panel
4188-424 issue 4_Part 1_10-09 22
Specification for the Repeat panel
Number of Zones
8 - Zone (standard size)
Colour
Front cover - Grey RAL 7000
Assembled panel size (in mm)
395 wide x 274 high x 87 deep
Weight (with batteries) approximate
5.8kg (2.1Ah battery) / 6.2Kg (with 3.4Ah battery)
Operating temperature and humidity
0 - 40
o
C low to +95% RH non condensing
Storage temperature and humidity
-5
o
C to +50
o
C low to +95% RH condensing
Approvals
Not applicable
Emission
BS EN50081-1:1992: Part 1 Residential, Commercial & Light industry
Class B limits
Immunity
BS EN50130-4: 1996: Part 4 Alarm systems : Electromagnetic compatibility
Product family standard:
Immunity requirements for components of fire
,
intruder and social alarm systems
IP rating (BS5490)
IP31 (indoor)
Flush fixing kit
13270-29 (Cut out required 378mm wide x 245mm high x 60mm deep)
Mains operating voltage
230V ac +10% -15% 50Hz
Knock-In cable entry points
Top & back entries
Terminal size
2.5mm
2
maximum
Battery supply (sealed lead acid)
2-off12V 2.1Ah - 3.4Ah (See applicable batteries as listed for Control panel
Standby duration
72hr standby
User access: By means of code entry
via numeric key pad
(AL1 Authorised user - No code is
required)
AL2 Site security 3 digit code - 123
AL3 Site engineering 3 digit code - 321
AL4 Engineers 4 digit code - 7426
Reset AL2 & AL3 codes 4 digit code - 2623
NOTE: Only a limited number of functions are accessible at the repeat panel
.
Key pad button controls Sound alarm, Silence alarm, System Reset & Cancel buzzer & numeric
keypad.
Buzzer for local audible indications Fire & System Fault - continuous sound Fault - intermittent sound
(via piezoelectric buzzer operating at 2 or 2.5KHz 70dB(A) at 1m)
Visual indications
FIRE & ZONES-fire (Red LEDs ‘lights’)
ZONES-fault, Fault, System, Power, Earth, Sounder, Disable, Test, Power,
Access/Function (Yellow LEDs ‘lights’)
Power on (Green LED ‘lights’)
Delay (LED ‘lights’)
Repeat panel (standard 8 zone)
A maximum of 1 repeat panel can be connected in series with the control
panel
Repeat panel connections
via serial port
