APPENDIX A GPU COMMUNICATION PROTOCOL
A.1 Introduction
The CIU 888 uses a communication protocol based on a request/reply
schedule. The protocol consists of command records and answer
records.
A record consists of a data field packed in an envelope. The envelope
allows the receiver to detect the incoming record and to verify its proper
reception.
A record consists of the following items:
The general form of a communication record is as follows:
A.2 Command records
The following records can be sent to the CIU.
 CIU individual command records, see section A.2.1
 Instrument individual command records, see section A.2.2
 Instrument group command records, see section A.2.3
STX DATAFIELD ETX BCC
Item Description
STX Start of Text Character (ASCII value 02)
DATA FIELD Data field packed in an envelope
ETX End of text character (ASCII value 03)
BCC Block Check Character
STX ADDRESS(ES) TOI TOR (DATA) ETX BCC
