12.0 CLASS 320 PROTOCOL DEFINITIONS

ModBus Customer Point Map: CL320

Address Registers Format Description Units

320

40001

2 Integer Energy delivered Wh Pulse R/W

40001

2 Integer Energy received Wh Pulse R/W

40005

2 Integer Reactive energy delivered VARh Pulse R/W

40007

2 Integer Reactive energy received VARh Pulse R/W

41001

2 Float Energy delivered kWh R/W

41003

2 Float Energy received kWh R/W

41005

2 Float Reactive energy delivered kVARh R/W

41007

2 Float Reactive energy received kVARh R/W

41009 2 Float Real power kW R

41011 2 Float Reactive power kVAR R

41013 2 Float Apparent power kVA R

41015 2 Float Power factor % PF R

41017 2 Float Peak demand kW R

41019 2 Float Current average Amps R

41021 2 Float Voltage line-neutral Volts-N R

41023 2 Float Voltage line-line Volts-L R

41025 2 Float Frequency Hz R

41027 2 Float Phase angle Degree R

41029 2 Float Real power, phase A kW R

41031 2 Float Real power, phase B kW R
